Tripp Lite PDU Metered ATS 120V 20A 5-15/20R 16 Outlet L5-20P Horizontal 1U
Tripp Lite PDU Metered ATS 120V 20A 5-15/20R 16 Outlet L5-20P Horizontal 1U - 16 x NEMA 5-15/20R - 2.4kVA - 1U Rack-mountable
| $736.95 | Retail $754.42 |
- Single phase 20A 120V Auto Transfer Switch / ATS PDU
- Enables redundant A/B power option for single-corded network devices
- Separate primary & secondary inputs connect to any two compatible power sources
- 1U horizontal rackmount; 2 NEMA L5-20P / 5-20P inputs; 16 5-15/20R outlets
Manufacturer:
Tripp Lite by Eaton
Item:
PDUMH20AT
UPC Code:
037332126665
Our Part #
TRPPDUMH20AT
Condition
New
$736.95EA
$754.42
$754.42
Availability
In Stock
You may be also interested
Product description
Tripp Lite PDU Metered ATS 120V 20A 5-15/20R 16 Outlet L5-20P Horizontal 1U - 16 x NEMA 5-15/20R - 2.4kVA - 1U Rack-mountable
16 x NEMA 5-15/20R - 2.4kVA - 1U Rack-mountable
Specifications
Broth Volume
16 x NEMA 5-15/20R
Cooling Type
037332126665 818214637765 818242779307
Cord Length
12
Cutting Depth at 45°
NEMA 5-15/20R
Depth
14.5"
Drying Capacity
Yes
Drying Load
PDUMH20ATNET
Energy Consumption (Self-cleaning)
NEMA L5-20P
Fastener Length
- PDUMH20AT PDU Metered ATS 120V 20A 16 Outlet
- PDU with attached L5-20P input power cord
- Detachable C19 to NEMA L5-20P 12 ft/3.6m power cord for optional secondary input
- Two NEMA L5-20R to NEMA 5-20P plug adapters
- User manual with warranty information
Heated
Taiwan
Height
1.8"
Internet Access
- 60950
- Class A
- RoHS Complaint
Lamp Base
- Optional Automatic Transfer Switch (ATS) function enables setup for hot-swappable UPS maintenance bypass
- Dual UPS protection or dual AC input redundancy for critical single-corded network hardware
- Slot for optional SNMPWEBCARD accessory to enable remote individual outlet control over IP
Maximum Gas Inlet Pressure
TAA Compliant
Maximum Open-Circuit Voltage
Tripp Lite
Maximum Operating Water Pressure
Tripp Lite Metered ATS / Auto Transfer Switch provides a redundant power option for single-corded network devices. Dual input cords support separate connection to PRIMARY and SECONDARY power sources. If the primary power source becomes unstable or fails altogether the ATS will switch over to the secondary power source until the primary input is restored and stable. Enables fault tolerant hot-swappable UPS protection when used with a single UPS and fully redundant UPS protection when each cord is connected to a separate UPS system. In a two-UPS environment the primary input cable must be supported by a full time sine wave UPS with zero transfer time. On-board ATS processor constantly evaluates power quality on both input sources to prevent transfer to the secondary source when unavailable or of lower quality than the primary source. Front input LED's display primary or secondary power availability.
Maximum Phone Number Supported
2
Maximum Pressure
Tripp Lite by Eaton
Maximum Pressure
PDUMH20AT PDU Metered ATS 120V 20A 16 Outlet
Maximum Weld Time
PDUMH20AT
Minimum Pressure
12.20 lb
Number Of Cartridges Included
120 V AC
Number of Cord/Cable
2
Number of Gliding Racks
Rack-mountable
Number of Pressure Settings
http://www.tripplite.com
Number of Pressure Settings
2 Year
Outfeed Roller Diameter
17.5"
Plug/Connector Detail
2 x NEMA L5-20P
Power Rating (VA)
2400 VA
Product Form
2400 VA
Receptacle Detail
16 x NEMA 5-15/20R
SEER
12
Table Diameter
1U
Table Width
1.8"
Table Width
14.5"
UPC Alternates
037332126665 818214637765 818242779307
UV Protection
2 x NEMA L5-20P
Width
17.5"
Wok Volume
PDU
Additional Information
TAA Compliant
Brand Name
Tripp Lite
Certifications & Standards
- 60950
- Class A
- RoHS Complaint
Cord Length
12
Country of origin
Taiwan
Depth
14.5"
Environmentally Friendly
Yes
Height
1.8"
Input voltage
120 V AC
Limited Warranty
2 Year
Management
- Optional Automatic Transfer Switch (ATS) function enables setup for hot-swappable UPS maintenance bypass
- Dual UPS protection or dual AC input redundancy for critical single-corded network hardware
- Slot for optional SNMPWEBCARD accessory to enable remote individual outlet control over IP
Manufacturer
Tripp Lite by Eaton
Manufacturer Part Number
PDUMH20AT
Manufacturer Website Address
http://www.tripplite.com
Marketing Information
Tripp Lite Metered ATS / Auto Transfer Switch provides a redundant power option for single-corded network devices. Dual input cords support separate connection to PRIMARY and SECONDARY power sources. If the primary power source becomes unstable or fails altogether the ATS will switch over to the secondary power source until the primary input is restored and stable. Enables fault tolerant hot-swappable UPS protection when used with a single UPS and fully redundant UPS protection when each cord is connected to a separate UPS system. In a two-UPS environment the primary input cable must be supported by a full time sine wave UPS with zero transfer time. On-board ATS processor constantly evaluates power quality on both input sources to prevent transfer to the secondary source when unavailable or of lower quality than the primary source. Front input LED's display primary or secondary power availability.
Mount Type
Rack-mountable
Package Contents
- PDUMH20AT PDU Metered ATS 120V 20A 16 Outlet
- PDU with attached L5-20P input power cord
- Detachable C19 to NEMA L5-20P 12 ft/3.6m power cord for optional secondary input
- Two NEMA L5-20R to NEMA 5-20P plug adapters
- User manual with warranty information
Plug/Connector Type
NEMA L5-20P
Product Model
PDUMH20ATNET
Product Name
PDUMH20AT PDU Metered ATS 120V 20A 16 Outlet
Product Type
PDU
Rack Height
1U
Receptacle Type
NEMA 5-15/20R
Weight (Approximate)
12.20 lb
Width
17.5"
